Kawasaki Vulcan 2000 Starter Solenoid Diagram

Description

Price

120

BOLT-SOCKET,6X14

120R0614

$3.75

120A

BOLT-SOCKET,6X25

120R0625

$4.18

551

PIN-DOWEL,6X14

551A0614

$3.92

555

PIN-SPRING

555B0316

$2.48

11061

GASKET

11061-0022

$8.82

13168

LEVER,JOINT

13168-0011

$7.35

13234

SHAFT-COMP

13234-0002

$15.55

13236

LEVER-COMP,SOLENOID

13236-0008

$22.23

14091

COVER

14091-0240

$102.96

21188

SOLENOID

21188-0005

$346.47

46102

ROD,PUSH

46102-0006

$27.35

92037

CLAMP,L=45

92037-1539

$5.00

92043

PIN,DECOMP

92043-0015

$15.55

92049

SEAL-OIL,RV37129.5

92049-016

$18.35

92145

SPRING,DECOMP RELEASE

92145-0037

$4.39

92170

CLAMP

92170-1804

$5.29

92171

CLAMP

92171-0322

$3.94
