Kawasaki TERYX® Seat(FGF/FHF) Diagram
#
Description
Price
11056
BRACKET
11056-7917
$7.59
13070
GUIDE
13070-0806
$1.84
13070A
GUIDE
13070-0807
$1.58
53007
FRAME-SEAT,FR,LH
53007-0375
$109.85
53007A
FRAME-SEAT,FR,RH
53007-0376
$109.85
53045
HOOK-ASSY
53045-0019
$7.79
53061A
BELT-SEAT,BUCKLE
53061-0039
$31.80
53061B
BELT-SEAT,RETRACTOR,L=2500
53061-0040
$156.61
53061C
BELT-SEAT,BUCKLE,SW.
53061-0338
$55.82
53066
SEAT-ASSY,BACK,BLK/SIL/GRN
53066-0394-41J
$433.25
53066A
SEAT-ASSY,BOTTOM,BLACK+SIL+GRN
53066-0533-41Y
$398.50
92022
WASHER
92022-2116
$2.34
92043A
PIN
92043-0882
$7.60
92143
COLLAR,8.8X12X11.5
92143-1340
$4.69
92145
SPRING,SEAT LATCH
92145-0022
$7.15
92145A
SPRING
92145-1682
$3.59
92154
BOLT,FLANGED,10X16
92154-2089
$7.35
92161
DAMPER,SEAT
92161-1489
$3.35
92200
WASHER,8.2X20.0X2.5
92200-0205
$3.35
92200A
WASHER,8.6X31X4.5
92200-1758
$2.17
130
BOLT-FLANGED,8X30
130BA0830
$1.98
130A
BOLT-FLANGED,12X20
130BA1220
$3.74
130B
BOLT-FLANGED,13X22
130BB1222
$4.72
132
BOLT-FLANGED-SMALL,8X25
132BA0825
$4.12
132A
BOLT-FLANGED-SMALL,6X14
132BB0614
$2.49
482
CIRCLIP-TYPE-E,8MM
482EA8000
$0.68
