Description

Price

1

CRANKSHAFT ASM. Substituted by 3084612 (Incl. 2-11, 21)

3084360

$999.99

2

CRANKSHAFT #1

3083362

Unavailable

3

CRANKSHAFT 2 (Incl. 6)

3083713

$583.49

4

CRANKSHAFT Substituted by 3085179

3084357

Unavailable

5

ROD-CONNECTING

3083252

$164.99

6

PIN,CRANK

3083233

$36.41

7

Pin, Crank, 2

3083456

Unavailable

8

SPACER(CRANKPIN)

3083277

$15.99

9

BEARING-LARGE END Substituted by 3085628

3083255

$31.75

10

SPACER,CRANKSHAFT

3080447

$1.99

11

BEARING, BALL Substituted by 3084586

3083480

$44.99

12

BALL BEARING, C-4

3083714

Unavailable

13

PISTON * (Standard) (Incl. 16)

3083942

Unavailable

13

PISTON,.020 O/S (.020 O/S) (Incl. 16)

3083944

Unavailable

13

PISTON,.010 O/S (.010 O/S) (Incl. 16)

3083943

Unavailable

14

Pin, Piston

3083838

$27.99

15

RING,PISTON,.010 O/S (.010 O/S)

3083970

Unavailable

15

RING,PISTON,.020 O/S (.020 O/S)

3083971

Unavailable

15

RING, PISTON,STD. (Standard)

3083963

Unavailable

16

CLIP,PISTON PIN,(10)

3083839

$4.75

17

BEARING, SMALL END Substituted by 3085595

3083216

$16.57

18

NUT

3083093

$19.99

19

WASHER-SPRING(10)

3083094

$3.17

20

KEY

3081447

Unavailable

21

GEAR,DRIVE,OIL PUMP

3083782

$102.13

Polaris SWE WIDE TRAK - S922064 PISTON and CRANKSHAFT WideTrak (4921302130037A) Diagram

CRANKSHAFT ASM. Substituted by 3084612 (Incl. 2-11, 21)

CRANKSHAFT #1

CRANKSHAFT 2 (Incl. 6)

CRANKSHAFT Substituted by 3085179

ROD-CONNECTING

PIN,CRANK

Pin, Crank, 2

SPACER(CRANKPIN)

BEARING-LARGE END Substituted by 3085628

SPACER,CRANKSHAFT

BEARING, BALL Substituted by 3084586

BALL BEARING, C-4

PISTON * (Standard) (Incl. 16)

PISTON,.020 O/S (.020 O/S) (Incl. 16)

PISTON,.010 O/S (.010 O/S) (Incl. 16)

Pin, Piston

RING,PISTON,.010 O/S (.010 O/S)

RING,PISTON,.020 O/S (.020 O/S)

RING, PISTON,STD. (Standard)

CLIP,PISTON PIN,(10)

BEARING, SMALL END Substituted by 3085595

NUT

WASHER-SPRING(10)

KEY

GEAR,DRIVE,OIL PUMP
