Kawasaki STS Water Muffler(JT750-B1) Diagram
#
Description
Price
110
BOLT,6X20
110R0620
$5.31
671
O RING,60MM
671B2560
$6.91
671A
O RING,WATER-MUFFLER
671C2550
$11.92
13183
PLATE
13183-3760
Unavailable
13183A
PLATE
13183-3818
Unavailable
18001
MUFFLER,WATER BOX,LWR
18001-3755
Unavailable
18001A
MUFFLER,WATER BOX,UPP
18001-3769
$133.00
18049
PIPE-EXHAUST,L=120
18049-3734
Unavailable
18049A
PIPE-EXHAUST,L=77.5
18049-3735
Unavailable
18150
PIPE-MUFFLER,WATER
18150-3701
Unavailable
18150A
PIPE-MUFFLER,WATER
18150-3702
Unavailable
92002
BOLT,6X25
92002-3714
$5.00
92002A
BOLT,6X45
92002-3717
$6.05
92002B
BOLT,6X16
92002-3728
$4.69
92002C
BOLT,6X20
92002-3755
$4.69
92022
WASHER,6.5X32X3
92022-3749
Unavailable
92022A
WASHER
92022-567
$2.67
92037
CLAMP
92037-3009
$3.70
92055
RING-O,WATER MUFFLER
92055-3718
$49.03
92062
NOZZLE,WATER MUFFLER
92062-3708
Unavailable
92066
PLUG,PT1/8X7
92066-1227
$5.90
92066A
PLUG
92066-3719
$7.59
92143
COLLAR,7.5X10.5X9
92143-3714
Unavailable
92143A
COLLAR,7.5X10.5X24
92143-3717
Unavailable
92160
DAMPER,FR
92160-3730
$6.47
92160A
DAMPER,LWR
92160-3732
$7.66
92160B
DAMPER,RR
92160-3774
Unavailable
92160C
DAMPER,WATER-MUFFLER
92160-3794
$5.66
92170
CLAMP
92170-3718
$13.67
92190
TUBE,WATER BOX-TAIL PIPE
92190-3880
$36.62
92191
TUBE,MUFFLER-WATER BOX
92191-3723
$46.55
