Kawasaki Ninja ZX-6R ABS KRT Edition Cowling Lowers(FHF/FHFA) Diagram

Description

Price

11056

BRACKET,SIDE COWLING,LH

11056-2186

$11.31

11056A

BRACKET,SIDE COWLING,RH

11056-2187

$11.31

39156

PAD,T10,COWLING LH

39156-0944

$30.10

39156A

PAD,T10,COWLING RH

39156-0945

$30.40

39156B

PAD,T20

39156-0958

$15.06

55028B

COWLING,FR,LH

55028-0448

$52.67

55028C

COWLING,FR,RH

55028-0449

$52.67

55028F

COWLING,LWR,FR,LH

55028-0452

$19.60

55028G

COWLING,LWR,FR,RH

55028-0453

$19.60

55057

COWLING,SIDE,LH,EBONY

55057-5121-H8

$662.41

55057A

COWLING,SIDE,RH,EBONY

55057-5122-H8

$664.63

55057B

COWLING,FIN,LH,L.GREEN

55057-5123-777

$186.88

55057C

COWLING,FIN,RH,L.GREEN

55057-5124-777

$185.52

55057D

COWLING,LWR,LH,M.F.S.BLACK

55057-5125-739

$470.26

55057E

COWLING,LWR,RH,M.F.S.BLACK

55057-5126-739

$462.57

92015

NUT,WELL,5MM

92015-1757

$7.29

92039

RIVET

92039-0051

$4.65

92039A

RIVET

92039-0068

$2.97

92075

DAMPER

92075-1983

$4.18

92153

BOLT,SOCKET,6MM

92153-0489

$3.73

92154

BOLT,SOCKET,5X16

92154-0209

$2.75

92172

SCREW,TAPPING,5X10

92172-0262

$1.34

92200

WASHER,NYLONE,5.3X11.5X0.5

92200-0006

$1.86

92200A

WASHER,10.4X15.9X0.5

92200-0157

$2.15
