Can-Am Commander 1000, 2011 07- Drive System, Front Diagram

#

Description
Price

1

Axle Drive Ass'y | Includes 1 to 7

705400915

$307.49

2a

Fixed Yoke Joint

715900116

$59.49

2b

FIX JOINT - Call your local BRP dealership

705400782

Unavailable

3

Ens. Croix*U-Joint Cross Kit

715900325

$70.99

4

Rubber Boot Kit | 4X4 / Includes 3 to 5

703500255

Unavailable

5

Oetiker Gear Clamp 44.0MM | 4X4

293650138

$8.89

5a

Collar | 4X4

705400148

Unavailable

6

GREASE FITTING - Call your local BRP dealership

715900067

Unavailable

7

Slip Joint

705500762

Unavailable

8

Wear Ring | 4X4

705400036

$26.49

9

Front Differential | Includes 8 to 31

703500907

$1,579.99

10

Oil Seal | 4X4

705401481

$19.49

11

Nut | 4X4

705401603

$35.99

12

Ball Bearing | 4X4

705500260

$31.99

13

10 TEETH PINION - Call your local BRP dealership

705501588

Unavailable

14

Needle Bearing

705501408

$69.99

15

Ball Bearing | 4X4

705401606

$51.99

16

Ball Bearing | 4X4

293350044

$31.99

17

Ens Differentiel*Differential Kit | 4X4

703500871

$749.99

18

Screw | 4X4

705401601

$10.49

19

FRONT COVER - Call your local BRP dealership

705400762

Unavailable

20

Seal | 4X4

705500265

$18.76

21

FRONT COVER - Call your local BRP dealership

705401136

Unavailable

22

VENT VALVE - Call your local BRP dealership | 4X4

705500893

Unavailable

23

Drain Plug | 4X4

705500894

$11.49

24

O-Ring | 4X4

705500267

$7.65

25

Gasket | 4X4

705401618

$18.49

26

Pinion Gear Shim 1.67 mm

705502061

$18.99

26

Pinion Gear Shim .022"

705500075

Unavailable

26

Pinion Gear Shim

705501162

$16.49

27

Shim | 4X4

705401604

$57.99

28

Fill Level Plug | 4X4

705500504

$10.01

29

Copper Washer | 4X4

705500506

$0.45

30

RH Front - Premium CV Axle | Includes 30 to 36

705401872

$243.99

31

CV Joint

705501238

Unavailable

32

Wheel Boot Kit

705500907

$42.49

32a

OETIKER CLAMP 71,1MM - Call your local BRP dealership

715900139

Unavailable

32b

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

Unavailable

33

Differential Boot Kit

705400512

$42.49

34

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

Unavailable

35

OETIKER CLAMP 67MM - Call your local BRP dealership

293650193

Unavailable

36

CIRCLIP - Call your local BRP dealership | 4X4

705400042

Unavailable

37

LH KNUCKLE - Call your local BRP dealership

705401008

Unavailable

38

RH KNUCKLE - Call your local BRP dealership

705401009

Unavailable

39

LH Front - Premium CV Axle | Includes 39 to 45

705401871

$243.99

40

CV Joint

705501238

Unavailable

41

Wheel Boot Kit

705500907

$42.49

41a

OETIKER CLAMP 71,1MM - Call your local BRP dealership

715900139

Unavailable

41b

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

Unavailable

42

Differential Boot Kit

705400512

$42.49

43

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

Unavailable

44

OETIKER CLAMP 67MM - Call your local BRP dealership

293650193

Unavailable

45

CIRCLIP - Call your local BRP dealership | 4X4

705400042

Unavailable

46

Ball Bearing

293350150

$52.99

47

Circlip

293370019

$4.68

48

Hex. Flange Screw M8 X 20, Scotch Grip

207582044

$1.69

49

Hex. Flange Screw M10 X 125

230602546

$7.41

50

Hex. Flange Elastic Nut M10

233201436

$2.11

51

Wheel Hub

705401314

$132.49

52

Wheel Stud

705401964

$11.06

53

Conical Spring Washer M18

250200171

$7.65

54

Hex. Flange Castellated Nut M18

232291413

$7.98

55

Cotter Pin

250400036

$2.11

56

Rubber Bellow | 4X4

705400552

$6.14

57

Oetiker Clamp

293650042

$3.09

58

WHEEL CAP - Call your local BRP dealership | XT

705400504

Unavailable

58

WHEEL CAP - Call your local BRP dealership

705400520

Unavailable

58

Wheel Cap | STD

705400921

$5.89

59

Front Tire

705402168

$248.99

59

TIRE_27X9R12 F - Call your local BRP dealership | STD

705400781

Unavailable

59

Front Tire 27X9X12 | X

705402560

$238.49

59

Front Tire | XT Europe

705400961

$248.99

60

Front Rim | XT International Except CAMO

705401378

$179.99

60

RIM_12 INCH X 6 - Call your local BRP dealership | STD

705400910

Unavailable

60

Front Rim

705400945

$170.49

60

Front Rim | XT CAMO

705401379

$216.99

62

1/2 Oz Weight

219704465

$3.89

63

REINFORCEMENT DISC PLATE - Call your local BRP dealership

705401248

Unavailable

64

Hex. Flange Screw M6 X 25

207662554

$1.48

65

Rim Valve With Cap

705400193

$8.69

65

VALVE_TIRE WITH CAP FORMED - Call your local BRP dealership | Xxc

705400872

Unavailable

66

Valve Cap

293000110

$1.59

66

VALVE CAP - Call your local BRP dealership

293000111

Unavailable

67

Steel Wheel Nut

250100042

$3.98

67

Chrome Wheel Nut M10 X 1.25 | XT

250100185

$8.79

67

Black, Wheel Nut M10 X 1.25

250100184

$4.51

68

Flat Washer M12

250200102

$2.11

69

Hex Flange Screw M12 X 16

250001039

$2.11

70

Loctite 271, 10 ml

293800005

$26.99

71

O-Ring

293250246

$7.51

72

Wear Sleeve

705400780

$7.90

73

Flat Washer M12

250200102

$2.11

74

HEX FLANGED SCREW M12 X 16, SCOTCH GRIP - Call your local BRP dealership

250000378

Unavailable

75

Synthetic Grease, 400 G

293550010

Unavailable
