Can-Am International - ORIGIN - E-Motor 20kw - SS73 - J8SB - Sterling Silver, 2025 04- Drive - Rear - Common Parts Diagram

Description

Price

10a

Machined Swing Arm

705503112

$466.49

10b

Dowel Pin

250400068

$2.11

Machined Final Drive Cover

705503810

$232.99

Ball Bearing, ID 12, OD 37, L 12

706002649

$14.81

Rear Wheel Axle | Includes 40 to 40a2

705503657

$317.99

40a2

Wheel Stud M10 X 1.25 | 2X4

250300055

$3.49

Drive Axle Ass'y | Includes 50 to 50c

705503684

$412.99

50b

Ball Bearing

293350187

$37.99

50c

Ball Bearing

293350147

$12.11

40 Teeth Sprocket

705503670

$169.49

Helical 23 Teeth Gear

705503431

$70.99

Flat Washer M8

250200187

$2.11

Hex. Flange Screw M8 X 12, Scotch Grip

207581244

$1.15

100

Needle Bearing

293350181

$24.49

110

Internal Retaining Ring

293370181

$6.95

120

Internal Retaining Ring

293370180

$6.79

130

Chain Slide

705503654

$65.99

140

Ball Bearing

293350182

$33.99

150

Retaining Ring

293370161

$6.79

160

Oil Seal

293200175

$17.99

170

Rear Wheel Sensor Ass'y

705503637

$43.99

180

Drive Chain, 104 Links

504153753

$174.99

190

Chain Tensioner Slide

705503652

$65.99

200

Chain Tensioner

705503909

$65.99

210

Circlip

293370105

$2.11

220

Adjustment Screw

705503135

$24.99

230

O-Ring

293300202

$1.01

240

Hair Pin

414575600

$1.89

250

Gasket

293300223

$11.65

260

Torx Screw Truss Head S.Grip M8 X 2

250001346

$5.39

270

Magnetic Plug

504155000

$12.49

280

Sealing Washer

250200114

$4.44

290

Torx Head Screw M6 X 16

250000717

$2.11

300

Torx Screw M6 X 1.0 X 18, Scotch Grip

250000779

$2.11

320

High Voltage Cable Support

712000033

$4.55

330

Torx Truss Screw M6 X 12

250000767

$2.00

340

Skid Plate

705503454

$51.99

350

Engine Cover

707002857

$14.49

370

Valve

705503691

$104.99

390

Lower Suspension Support

705503693

$12.49

400

Cable Support

706206319

$31.49

410

Socket Head Screw M4 X 12

205041254

$2.11
