Can-Am ST, 2016 09- Body And Accessories - Front Fender Diagram

#

Description
Price

8

Hex. Flange Screw M6 X 20

207662054

$1.01

14

Hex. Elastic Stop Nut M6

232561600

$1.15

25

Torx Screw M6 X 20, Scotch Grip

250000446

$4.44

29

Torx Screw M5 X 20

250000724

$1.69

30

Plastite Screw M4 X 10

250000805

$2.11

31

Torx Screw M6 X 14

250000851

$2.11

34

Pressure Nut

250100163

$0.98

35

Panel Nut M5 X 0.8

250100176

$4.09

38

M6 Nut Housing Ass'y | Includes 290 to 290b

269500252

$7.86

39

M6 Nut Housing Ass'y | Includes 7r to 7r2

269500725

$4.55

41

Tie Wrap 142 mm

293750002

$1.25

57

Reflective Stripe

704901160

$10.99

67

LH Mudguard | Model-RS STD

705001767

$51.99

76

Central Front Fender Support | Model-RS STD

705002389

$62.99

77

Amber, Lateral Reflector

705002423

$15.49

87

Not Available As Spare Part - Friction Washer

Unavailable

92

Metallic Black Front Fender LH | Model-RS S

705006908

$204.99

92

Metallic Black Front Fender RH | Model-RS S

705006909

$309.99

102

Carbone Black Front Fender Moulding LH | Model-RS S

705006912

$204.99

102

Carbone Black Front Fender Moulding RH | Model-RS S

705006913

$204.99

108

LH Rear Reflector | Model-RS S North America

705005667

$30.99

108

RH Rear Reflector | Model-RS S North America

705005949

$30.99

108

LH Rear Reflector Ass'y | Model-S Europe, Australie, Brezil, Japon

219800275

$15.49

108

RH Rear Reflector Ass'y | Model-S Europe, Australie, Brezil, Japon

219800276

$15.49

131

Yellow LH Reflector | Model-RS S

705008661

$30.99

131

Yellow RH Reflector | Model-RT LTD

705008662

$30.99

135

LH Support | Model-RS S

219800414

$86.99

135

Rh Painted Fender Rear Support Kit | Model-RS S

219800398

$86.99

137

Lh Painted Fender Front Support Kit | Model-RS S

219800497

$86.99

137

Rh Painted Fender Front Support Kit

219800396

$86.99

139

LH PAINTED FENDER REAR SUPPORT - Call your local BRP dealership

705010100

$76.99

141

LH Painted Fender Front Support | Model-RS STD

705010102

$86.99

150

Position Light | STD Model

710003295

$62.49

154

LH Position Light

710004032

$83.49

154

RH Position Light

710004033

$83.49

158

Panel Nut M6 X 1.0

250100198

$2.11

159

LH Inner Fender | Model-RS S

705007616

$56.99

159

RH Inner Fender | Model-RS S

705007617

$56.99

160

Hex Screw Washer Head M8 X 20

207582054

$3.17
