Can-Am Renegade, 2017 09- Rear Cargo Box - All Models Diagram

Description

Price

90>90a

Tool Kit

704700168

$40.99

90a

Socket Wrench 14/16MM

529000085

$6.55

100

Flag Support | Except Europe

705005837

$7.89

100

Black, Flag Support | Package XXC, Model Black

705015697

$7.19

160

Adjustment Wrench

529000035

$2.09

170

Kit Rear Bumper

715001894

$248.99

170

Blue Rear Bumper | Package XMR Blue

705009740

$381.49

170

Red Rear Bumper | Package XMR Red

705010641

$381.49

170

Black Rear support | Package XXC, Model Black

705011052

$222.49

175

Cap

705202455

$5.69

180

Rear Tube

705004981

$28.99

180

Black Paint Tube | Package XXC, Model Black

705015730

$27.99

190

Threaded Insert M6 X 1.0

250100242

Unavailable

200

Torx Screw M6 X 20

250000712

$2.11

205

Flat Washer

224061201

$1.37

210

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.47

220

LH Front Bracket

705004977

$34.99

230

RH Front Bracket

705004978

$34.99

240

Torx Screw M8 X 50 S.GRIP

250000844

$6.77

250

Button Head Torx Screw M8 X 25 S.Gr

250000757

$2.00

255

Hex. Flange Screw M8 X 25

207682534

$2.11

255

Hex. Flange Screw M8 X 50

207685044

$1.69

265

Flat Washer 6 mm

234062410

$0.77

270

Hex. Screw M6 X 60

207066044

$0.67

280

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.47

290

Hex. Flange Elastic Nut M8

233281414

$1.47

310

Tie Wrap 368 mm

293750008

$1.04
