Can-Am Rally, 2003 01- Crankshaft, Piston And Cylinder Diagram

#

Description
Price

1

Gasket

711650165

Unavailable

2

Cylinder Ass'y | Includes 2 - 3.

711613346

Unavailable

3

Drive Pin 5 X 10

420929650

$1.68

4

GASKET - Call your local BRP dealership

711650172

Unavailable

5

Cylinder Head Ass'y | Includes 5 - 7.

711613110

Unavailable

6

Valve Guide

711253811

Unavailable

7

PROTECTION PLUG - Call your local BRP dealership

420960775

Unavailable

8

Stud

711240366

Unavailable

9

Hex. Nut M8

420842616

$5.29

10

Socket Screw M6 x 90

711241481

Unavailable

11

Socket Head Screw M6 X 30

205063044

$1.69

12

Thermostat 65° With Gasket Ass'y | Includes 42 to 43

420222494

$53.99

13

Thermostat Gasket

420650300

$8.57

14

Thermostat Cover

711222470

Unavailable

15

Screw M5 X 16

420441621

$3.17

16

Gasket Ring

420650255

$4.12

17

Socket Screw M5 x 12

711241841

Unavailable

18

Washer 5.3

420927574

$1.90

19

Hose Clamp

711251052

Unavailable

20

Chain Tension Piston

711236490

Unavailable

21

Compression Spring

711238100

Unavailable

22

Hex. Screw M18 x 10

711552276

Unavailable

23

Crush Washer

420552280

$3.70

24

Valve Cover

711610440

Unavailable

25

Valve Cover Gasket

711650230

Unavailable

26

Socket Head Screw M6 X 20

205062044

$1.26

27

Thermostat Fan Switch

711265392

Unavailable

28

Gasket Set

711296407

Unavailable

29

Loctite 243, 10 ml

293800060

$21.49

30

LUBRICANT LOCTITE LB 8150 236ML - Call your local BRP dealership

219704461

Unavailable
