Can-Am Traxter XT, 2002 01- Exhaust System Diagram

#

Description
Price

1

Tuned Pipe

707600062

Unavailable

2

GASKET - Call your local BRP dealership

707600003

Unavailable

3

Hex. Flange Screw M8 X 12, Scotch Grip

207581244

$1.15

4

Hex. Flange Nut M8

233081416

$1.15

5

Muffler | Includes 5 To 6

707600080

Unavailable

6

Drain Plug

250500003

Unavailable

7

Was 293800041 Loctite Primer 7649

219704458

$39.99

8

Loctite 243, 10 ml

293800060

$21.49

9

Stud M8 x 23

711940366

Unavailable

10

Hex. Flange Elastic Nut M8

233281414

$1.47

11

Heat Shield

707600076

Unavailable

12

Hex. Flange Screw M6 X 10

210261040

$1.48

13

Spring

415107100

$6.35

14

Rotax 4 Strokes Engine «511» | Includes 1 to 7

707000041

Unavailable

15

Spark Plug, NGK/DR8EA

707000008

$4.23

16

Front Engine Bracket, Black

707000082

Unavailable

17

Hex. Screw M4 X 16, Scotch Grip

207341644

Unavailable

18

Tie Rod Ass'y

707000068

Unavailable

19

Hose Retainer 13 mm

705600232

$11.11

20

Anti-Vibration Mount

707000094

Unavailable

21

Synthetic Grease, 400 G

293550010

Unavailable

22

Spacer

707000181

Unavailable

23

ENGINE SUPPORT BUSHING - Call your local BRP dealership

707000019

Unavailable

24

Support Bushing | Includes 10 to 11

707000030

Unavailable

25

RH LOWER BUSHING - Call your local BRP dealership

707000004

Unavailable

26

Engine Bracket

705200197

Unavailable

27

Hex. Flange Screw M10 X 140

230604044

$5.29

28

HEX. FLANGED SCREW M10 X 95 - Call your local BRP dealership

207609544

Unavailable

29

Hex. Flange Elastic Nut M10

233201414

$1.58

30

Hex. Flange Screw M8 X 20

207682044

$1.15

31

CARBURATOR ADAPTOR - Call your local BRP dealership

707000247

Unavailable

32

Clamp

512059062

Unavailable

33

CARBURATOR ASS?Y BSR33-29 - Call your local BRP dealership

707200157

Unavailable

34

Gear Clamp Gemi

293650094

Unavailable

35

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.47

36

Shim 1.0 mm

707000080

Unavailable

Shim 2.0 mm

707000081

Unavailable

37

Anti-Vibration Rubber

707600702

$8.57

38

Hex. Flange Screw M6 X 20

207662044

$2.00

39

LEVER ASS'Y - Call your local BRP dealership

707000010

Unavailable

40

LEVER BUTTON - Call your local BRP dealership

705500022

Unavailable

41

Adjuster Bushing

705500193

Unavailable

42

BUSHING - Call your local BRP dealership

705500150

Unavailable

43

LEVER SPRING - Call your local BRP dealership

705500024

Unavailable

44

Hex. Flange Screw M8 X 50

207685044

$1.69

45

Upper Tube, Black

705500358

Unavailable

46

Lower Tube

705500135

Unavailable

47

Hex. Flange Screw M6 X 35

207663544

$0.90

48

Hex. Flange Screw M6 X 16

207661644

$0.74

49

RETAINER CLAMP - Call your local BRP dealership

705500041

Unavailable

50

Half Ring

705500033

$8.29

51

Carburator Support

707200159

Unavailable

52

Grommet

709000582

$4.69

53

Hex. Flange Screw M6 X 20

207662044

$2.00

54

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.47
