Can-Am Outlander L MAX 500 EFI, 2015 07- Drive System, Front _12T1504 Diagram

#

Description
Price

5

Not Available As Spare Parts

XXX

Unavailable

6

Hex. Flange Screw M8 X 55

207685544

$5.39

7

Hex. Flange Screw M10 X 125

230602546

$7.41

8

Hex. Flange Castellated Nut M18

232291413

$7.98

9

Hex. Flange Elastic Nut M10

233201436

$2.11

10

Hex. Flange Elastic Nut M8

233281414

$1.47

11

Not Available As Spare Parts

XXX

Unavailable

12

Not Available As Spare Parts

XXX

Unavailable

13

Not Available As Spare Parts

XXX

Unavailable

15

Hex Flange Screw M12 X 20

250001042

$1.90

16

Steel Wheel Nut

250100042

$3.98

17

Chrome Wheel Nut M10 X 1.25 | XT

250100185

$8.79

18

Conical Spring Washer M18

250200171

$7.65

19

Flat Washer M10 | 4X4

250200014

$1.49

20

Wheel Stud | Tightening Torque: See Bulletin ATV 2020-4

250300643

$5.03

21

Not Available As Spare Parts

XXX

Unavailable

22

Cotter Pin

250400036

$2.11

24

Valve Cap

293000110

$1.59

25

Not Available As Spare Parts

XXX

Unavailable

26

Not Available As Spare Parts

XXX

Unavailable

28

Not Available As Spare Parts

XXX

Unavailable

29

Ball Bearing

293350150

$52.99

31

Circlip

293370019

$4.68

32

Not Available As Spare Parts

XXX

Unavailable

33

Not Available As Spare Parts

XXX

Unavailable

38

Oetiker Gear Clamp 44.0MM | 4X4

293650138

$8.89

39

Oetiker Gear Clamp

293650199

$9.69

43

Tie-Rap 180 mm

414115200

$0.11

45

Oetiker Gear Clamp, 36.5-706R

509000529

$9.95

47

Wear Ring | 4X4

705400036

$26.49

48

Circlip Joint | Not shown

705401349

$6.50

49

Not Available As Spare Parts

XXX

Unavailable

50

Rim Valve With Cap

705400193

$8.69

51

Not Available As Spare Parts

XXX

Unavailable

62

Tire 205 X 80 R12

705402890

$153.49

62

Front Tire | STD Europe

705401626

$224.99

63

Tire 205 X 80 R12

705402890

$153.49

63

Front Tire | STD Europe

705401626

$224.99

65

Not Available As Spare Parts

XXX

Unavailable

75

Not Available As Spare Part - Friction Washer

Unavailable

76

CV Boot Kit, Wheel Side

715900298

$42.49

77

Not Available As Spare Part - Friction Washer

Unavailable

83

CV Boot Kit, Differential Side

715900299

$42.49

84

Not Available As Spare Part - Friction Washer

Unavailable

85

Not Available As Spare Part - Friction Washer

Unavailable

88

Not Available As Spare Parts

XXX

Unavailable

97

Propeller Shaft | Includes 1 to 2

705400913

$211.99

99

Oetiker Gear Clamp 36.1MM

509000045

$8.29

100

Rubber Boot

715900118

$14.30

101

Universal Joint Kit

703500845

$78.49

102

Grease Fitting | T3

715900295

$5.24

103

Wheel Cap

705400928

$10.49

105

Not Available As Spare Parts

XXX

Unavailable

106

Rubber Boot

705401093

$5.00

109

CV Joint

715900297

$259.49

110

RH Front - Premium CV Axle

705401428

$243.99

110

LH Front - Premium CV Axle

705401429

$243.99

111

RH Plunging CV Joint

715900300

$259.49

111

LH Plunging CV Joint

715900301

$259.49

116

Black,12" X 6 Rim | STD

705401199

$119.99

117

Front Bushing Shaft Kit | 4X4

703500678

$114.99

119

LH Knuckle

705403307

$179.99

119

RH Knuckle

705403308

$179.99

121

Silver Rim | Package-DPS

705401402

$190.49

122

Polyurethane Hose 10000Mm Long

219704410

$56.99

126

YOKE JOINT - Call your local BRP dealership

715900293

Unavailable

127

Fixed Yoke Joint

715900116

$59.49

128

Rubber Boot

715900118

$14.30

130

Not Available As Spare Parts

XXX

Unavailable

132

Not Available As Spare Parts

XXX

Unavailable

133

Not Available As Spare Parts

XXX

Unavailable

140

Fill Level Plug | 4X4

705500504

$10.01

141

Copper Washer | 4X4

705500506

$0.45

146

1/2 Oz Weight

219704465

$3.89

149

Wheel Hub Ass'y

705501716

$105.99

150

Not Available As Spare Parts

XXX

Unavailable

151

Not Available As Spare Parts

XXX

Unavailable
