Description

Price

1

Front Drive Axle Ass'y | 4X4 / Includes 1 to 5

705400912

$179.99

2a

Rubber Boot Kit | 4X4 / Includes 3 to 5

703500255

Unavailable

2b

Oetiker Gear Clamp 44.0MM | 4X4

293650138

$8.89

6

Front Bushing Shaft Kit | 4X4

703500678

$114.99

7

Wear Ring | 4X4

705400036

$26.49

8

Front Differential | Includes 8 to 31

703500907

$1,579.99

9

Oil Seal | 4X4

705401481

$19.49

10

Nut | 4X4

705401603

$35.99

11

Ball Bearing | 4X4

705500260

$31.99

12

10 TEETH PINION - Call your local BRP dealership

705501588

Unavailable

13

Needle Bearing | 4X4

705500261

$19.99

14

Ball Bearing | 4X4

705401606

$51.99

15

Ball Bearing | 4X4

293350044

$31.99

16

Ens Differentiel*Differential Kit | 4X4

703500871

$749.99

19

Screw | 4X4

705401601

$10.49

20

FRONT COVER - Call your local BRP dealership

705400762

Unavailable

21

Seal | 4X4

705500265

$18.76

22

Front Cover

705400646

Unavailable

23

VENT VALVE - Call your local BRP dealership | 4X4

705500893

Unavailable

24

Drain Plug | 4X4

705500894

$11.49

27

O-Ring | 4X4

705500267

$7.65

28

Gasket | 4X4

705401618

$18.49

29

Pinion Gear Shim 1.67 mm

705502061

$18.99

29

Pinion Gear Shim .022"

705500075

Unavailable

30

Shim | 4X4

705401604

$57.99

31

Shim | 4X4

705401604

$57.99

32

Fill Level Plug | 4X4

705500504

$10.01

33

Copper Washer | 4X4

705500506

$0.45

34

RH Half Shaft | Includes 34 to 39

705401579

$243.99

35

CV Joint

705500560

Unavailable

36

Wheel Boot Kit

705400511

$42.49

36a

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

Unavailable

36b

OETIKER CLAMP 70MM - Call your local BRP dealership

293650194

Unavailable

37

Differential Boot Kit

705400512

$42.49

37a

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

Unavailable

37b

OETIKER CLAMP 67MM - Call your local BRP dealership

293650193

Unavailable

39

CIRCLIP - Call your local BRP dealership | 4X4

705400042

Unavailable

40

LH Knuckle

705400816

$206.49

41

RH Knuckle

705400818

$206.49

42

LH Half Shaft | Includes 42 to 47

705401578

$243.99

43

CV Joint

705500560

Unavailable

44

Wheel Boot Kit

705400511

$42.49

44a

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

Unavailable

44b

OETIKER CLAMP 70MM - Call your local BRP dealership

293650194

Unavailable

45

Differential Boot Kit

705400512

$42.49

45a

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

Unavailable

45b

OETIKER CLAMP 67MM - Call your local BRP dealership

293650193

Unavailable

47

CIRCLIP - Call your local BRP dealership | 4X4

705400042

Unavailable

48

Ball Bearing

293350150

$52.99

49

Oetiker Gear Clamp 44.0MM | 4X4

293650138

$8.89

50

Circlip

293370019

$4.68

51

Hex. Flange Screw M10 X 125

230602546

$7.41

52

Hex. Flange Elastic Nut M10

233201436

$2.11

53

Wear Sleeve | 4X4

705501121

$7.90

54

LH WHEEL HUB ASSEMBLY - Call your local BRP dealership | 4X4 / Includes 65 to 66

705501713

$137.47

55

Wheel Stud M10 X 1.25 | 2X4

250300055

$3.49

56

Conical Spring Washer M18

250200171

$7.65

57

Hex. Flange Castellated Nut M18

232291413

$7.98

58

Cotter Pin

250400036

$2.11

59

Rubber Bellow | 4X4

705400552

$6.14

60

Oetiker Clamp

293650042

$3.09

61a

WHEEL CAP - Call your local BRP dealership

705400680

$15.49

61b

Wheel Cap | STD

705400563

$18.99

62

Front Tire | XT

705400606

$134.99

62

Front Tire | XT

705400326

$134.99

62

Front Tire | STD Europe

705401626

$224.99

62

Tire 205 X 80 R12

705402890

$153.49

63a

RIM_12 INCH X 6 - Call your local BRP dealership | XT (Except Camo)

705400648

Unavailable

63b

RIM_12 INCH X 6 - Call your local BRP dealership | STD

705400689

Unavailable

64a

Rim Valve With Cap

705400193

$8.69

64b

1/2 Oz Weight

219704465

$3.89

64c

Valve Cap

293000110

$1.59

65

Steel Wheel Nut

250100042

$3.98

65

Chrome Wheel Nut M10 X 1.25 | XT

250100185

$8.79

66

Wear Sleeve

705400780

$7.90

67

Flat Washer M12

250200102

$2.11

68

HEX FLANGED SCREW M12 X 16, SCOTCH GRIP - Call your local BRP dealership

250000378

Unavailable

70

Synthetic Grease, 400 G

293550010

Unavailable

71

HOUSING - Call your local BRP dealership | 4X4

705400169

Unavailable

72

Actuator Ass'Y | Includes 72 to 74

715900502

$499.99

72a

Circlip | 4X4

293370042

$3.17

73

Fork | 4X4

705400274

$18.99

74

O-Ring

293300117

$4.44

75

Hex. Flange Screw M8 X 20, Scotch Grip | 4X4

250000137

$3.28

76

UNION SHAFT - Call your local BRP dealership | 4X4

705400917

Unavailable

77

Pressure Screw M8 X 8 | 4X4

206580890

$1.69

78

Dowell Pin | 4X4

250400025

$7.73

79

Ball Bearing | 4X4

705400249

$25.99

80

Slider | 4X4

705402139

$46.99

81

Circlip | 4X4

293370029

$5.19

82

Circlip | 4X4

293370030

$2.89

83

SWITCH - Call your local BRP dealership | 4X4

710000324

$28.99

84

Coupling Sleeve | 4X4

705400389

$31.99

85

Oil Seal | 4X4

293250138

$23.99

86

Shifter Lever Plate | 4X4

705401553

$20.99

87

Copper Washer

705601628

$4.44

88

Loctite 243, 10 ml

293800060

$21.49

89

Socket Head Screw M8 X 20, Scotch Grip

250000136

$3.70

90

O-Ring

293300091

$7.51

Can-Am Outlander Max 400 EFI, 2011 07- Drive System, Front Diagram
