Can-Am Maverick MAX 1000_STD_XRS-DPS, 2015 07- Drive System, Front _12C1509a Diagram

#

Description
Price

1

Hex. Flange Screw M8 X 20, Scotch Grip

207582044

$1.69

2

Hex. Flange Screw M10 X 25

207602544

$1.69

3

Hex. Flange Screw, M10 X 130

230603046

$7.41

4

Hex. Flange Castellated Nut M18

232291413

$7.98

5

Hex. Flange Elastic Nut M10

233201414

$1.58

6

Hex. Flange Elastic Nut M10

233201436

$2.11

7

Conical Spring Washer 10 mm

234201474

$1.69

8

Hex. Flange Screw M6 X 25

250000787

$2.22

10

Black, Wheel Nut M10 X 1.25

250100184

$4.51

12

Conical Spring Washer M18

250200171

$7.65

13

Wheel Stud

250300060

$11.49

14

Cotter Pin

250400036

$2.11

15

Valve Cap

293000110

$1.59

16

O-Ring

293250246

$7.51

17

Ball Bearing

293350150

$52.99

18

Circlip

293370019

$4.68

21

Tie-Rap 180 mm

414115200

$0.11

22

Washer

503032900

$3.28

23

Wear Ring | 4X4

705400036

$26.49

24

Wear Sleeve

705400780

$7.90

25

Wheel Cap

705400928

$10.49

26

Deep Black, 12" X 6 Rim | STD

705401417

$190.49

26

Black, Rim | XXC

705401678

$260.99

28

Rim Valve With Cap

705400193

$8.69

36

Fixed Yoke Joint

715900116

$59.49

38

Yoke Joint | Cover 715900483

715900231

$26.49

40

GREASE FITTING - Call your local BRP dealership

703500813

Unavailable

41

U-Joint

715900183

$26.49

42

Drive Shaft Assembly

705402068

$238.49

46

Boot Kit, Differential Side

705401346

$42.49

47

Boot Kit, Wheel Side

705401345

$42.49

48

CV Joint

705401344

$259.49

50

Oetiker Clamp, Large

715900284

$5.29

51

Oetiker Clamp, Small

715900261

$5.29

52

Oetiker Clamp

715900282

$5.29

53

Oetiker Clamp, Small

715900283

$5.29

55

RH Plunging Joint

705401348

$259.49

55

LH Plunging Joint

705401350

$259.49

56

RH CV Joint

705401874

$243.99

56

LH CV Joint

705401873

$243.99

57

Drive Axle Ass'y | Model-COM-MAX

705402041

$413.49

62

SNAP RING - Call your local BRP dealership

715900117

Unavailable

63

U-Joint

715900183

$26.49

64

GREASE FITTING - Call your local BRP dealership

703500813

Unavailable

65

Yoke Joint | Cover 715900483

715900231

$26.49

68

Yellow Reinforcement Disc

705401329

$85.99

68

Red Reinforcement Disc | XRS-DPS White, Except EUR

705401445

$85.99

77

Front Tire 27X9X12 | X

705402560

$238.49

91

Ball Bearing | Model-COM-MAX

705401646

$62.49

98

LH Front Knuckle

705401548

$132.49

98

RH Front Knuckle

705401549

$104.99

118

Fill Level Plug | 4X4

705500504

$10.01

119

Copper Washer | 4X4

705500506

$0.45

120

1/2 Oz Weight

219704465

$3.89

123

Wheel Hub

705501900

$132.49

124

Polyurethane Hose 10000Mm Long

219704410

$56.99

134

Ens. Croix*U-Joint Cross Kit

715900325

$70.99

135

SNAP RING - Call your local BRP dealership

715900117

Unavailable

136

Ens. Croix*U-Joint Cross Kit

715900325

$70.99

137

Circlip Joint | Not shown

705401349

$6.50

138

Insert | XXC

293450317

$7.29

139

Grease Fitting

703500815

$5.24

140

Grease Fitting

703500815

$5.24
