Can-Am Maverick 1000_XDS-DPS, 2015 07- Drive System, Front _12C1510a Diagram

#

Description
Price

5

Hex. Flange Screw M8 X 20, Scotch Grip

207582044

$1.69

6

Not Available As Spare Parts

XXX

Unavailable

7

Hex. Flange Screw, M10 X 130

230603046

$7.41

8

Hex. Flange Castellated Nut M18

232291413

$7.98

9

Not Available As Spare Parts

XXX

Unavailable

10

Hex. Flange Elastic Nut M10

233201436

$2.11

11

Conical Spring Washer 10 mm

234201474

$1.69

12

Hex. Flange Screw M6 X 25

250000787

$2.22

12a

Insert | XXC

293450317

$7.29

13

Hex. Flange Screw M10 X 16 S.GRIP

250001044

$2.11

14

Black, Wheel Nut M10 X 1.25

250100184

$4.51

15

Flat Washer M10 | 4X4

250200014

$1.49

16

Conical Spring Washer M18

250200171

$7.65

17

Wheel Stud

250300060

$11.49

18

Cotter Pin

250400036

$2.11

19

Valve Cap

293000110

$1.59

20

O-Ring

293250246

$7.51

21

Ball Bearing

293350150

$52.99

22

Circlip

293370019

$4.68

29

Tie-Rap 180 mm

414115200

$0.11

30

Not Available As Spare Parts

XXX

Unavailable

32

Wear Ring | 4X4

705400036

$26.49

33

Wear Sleeve

705400780

$7.90

34

Wheel Cap

705400928

$10.49

35

Rim Valve With Cap

705400193

$8.69

36

Drive Shaft Assembly

705402068

$238.49

37

Fixed Yoke Joint

715900116

$59.49

39

Yoke Joint | Cover 715900483

715900231

$26.49

41

GREASE FITTING - Call your local BRP dealership

703500813

Unavailable

42

Ens. Croix*U-Joint Cross Kit

715900325

$70.99

42a

U-Joint

715900183

$26.49

45

Boot Kit, Differential Side

705401346

$42.49

46

Boot Kit, Wheel Side

705401345

$42.49

47

CV Joint

705401344

$259.49

49

Oetiker Clamp, Large

715900284

$5.29

50

Oetiker Clamp, Small

715900261

$5.29

51

Oetiker Clamp

715900282

$5.29

52

Oetiker Clamp, Small

715900283

$5.29

54

RH Plunging Joint

705401348

$259.49

54

LH Plunging Joint

705401350

$259.49

54a

Circlip Joint | Not shown

705401349

$6.50

55

RH CV Joint

705401874

$243.99

55

LH CV Joint

705401873

$243.99

56

Not Available As Spare Parts

XXX

Unavailable

61

SNAP RING - Call your local BRP dealership

715900117

Unavailable

62

Not Available As Spare Parts

XXX

Unavailable

62a

Not Available As Spare Parts

XXX

Unavailable

63

Not Available As Spare Parts

XXX

Unavailable

64

Not Available As Spare Parts

XXX

Unavailable

71

Not Available As Spare Parts

XXX

Unavailable

74

LH Front Knuckle

705401548

$132.49

74

RH Front Knuckle

705401549

$104.99

76

Black Rim | Package XTP Except Europe

705401594

$297.99

76

Deep Black, 12" X 6 Rim | STD

705401417

$190.49

78

Manta Green, Reinforcement Disk | Model Mineral Gray Satin

705401586

$92.99

99

Fill Level Plug | 4X4

705500504

$10.01

100

Copper Washer | 4X4

705500506

$0.45

102

Front Tire | STD Europe Model

705401046

$144.99

102

Front Tire Maxxis 28X9X14 | Model-North America, International

705402080

$259.49

104

Wheel Hub

705501900

$132.49

105

Polyurethane Hose 10000Mm Long

219704410

$56.99
