Can-Am Commander 1000_STD_DPS_XT_XTP, 2015 07- Steering _23C1502 Diagram

#

Description
Price

5

Hex. Screw M6 X 30

207063044

$1.26

6

Hex. Screw M10 X 35

207103586

$1.15

7

Hex. Flange Screw M8 X 16, Scotch Grip

207581644

$1.15

8

Hex. Flange Screw M8 X 35, Scotch Grip | Sub 250000986

207583586

Unavailable

9

Hex. Flange Screw M10 X 25

207602546

$2.11

10

Hex. Flange Screw M8 X 30 | DS 650 X

207683044

$1.69

11

Cotter Pin

211400017

$0.33

12

Hex. Screw M10 X 100, Scotch Grip

230500046

$7.41

13

Elastic Stop Nut M10

232500416

$1.90

14

Elastic Stop Nut M12

232521416

$1.69

15

Elastic Stop Nut M6

232561434

$1.99

16

Hex. Flange Elastic Nut M10

233201436

$2.11

17

Hex. Flange Elastic Nut M12

233221414

$7.69

18

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.47

19

Hex. Flange Elastic Nut M8

233281414

$1.47

20

Hex. Elastic Flange Nut M8

233281416

$1.48

21

Panel Nut M6 X 1.0

250100198

$2.11

22

Truss Head Torx Screw K50 X 20

250000297

$2.11

23

Socket Head Screw M8 X 16

250000669

$3.17

24

Hexagonal Screw M12 X 88

250000657

$6.77

25

Torx Truss Screw M6 X 16

250000721

$1.69

26

Torx Screw M6 X 20

250000722

$1.68

27

Phillips Screw K40 X 16

250000723

$0.98

28

O-Ring

293300144

$3.82

31

Bushing

293900106

$4.55

34

Tie-Rap 180 mm

414115200

$0.11

35

Steering Bushing

709402725

$3.28

36

Bushing

705600799

$3.72

37

Hardened Washer

706200281

$2.85

38

Cluster Support | X, XT

707900013

$16.49

39

Upper Cluster Cover | X, XT

707900124

$16.49

40

Speedometer Cover

709400514

$16.99

41

Latch Indicator Cover

709400573

$11.99

42

Steering Wheel | STD

709400650

$137.49

47

Adjustment Cylinder

709402506

$72.99

50

Cluster Support | STD

709400760

$21.99

51

Steering Center | STD

709400780

$13.49

52

STEERING WHEEL KIT - Call your local BRP dealership | X, XT Includes 3 to 5

715001134

$194.99

64

RH DPS SUPPORT - Call your local BRP dealership

709401128

Unavailable

68

Ball Joint

709401134

$52.99

69

Steering Shaft

709401167

$48.99

74

Nut Tie Rod End

715900237

$14.30

76

Boot Tube Side

709401232

$18.99

80

Painted Steering Wheel Support

709401391

$85.99

81

LH DPS Support | Package-DPS, XT, XTP

709401485

$11.99

82

Machined Coupling | Package-DPS, XT, XTP

709401494

$33.99

86

Not Available As Spare Parts

XXX

Unavailable

91

STEERING SHAFT ASS'Y - Call your local BRP dealership | Package-DPS, XT, XTP

709401499

Unavailable

92

Rack And Pinion Steering

709402387

$487.49

93

Boot Kit, Pinion Side

715900235

$54.99

94

Boot Kit, Tube Side

715900236

$54.99

95

Power Steering Ass'y | Package-DPS, XT, XTP

709401921

$999.49
