Can-Am Maverick 1000_XMR, 2014 07- Drive System, Front _12C1406 Diagram

#

Description
Price

10

Drive Shaft Assembly

705402068

$238.49

10a

Grease Fitting

703500815

$5.24

10b

GREASE FITTING - Call your local BRP dealership

703500813

Unavailable

10d

Yoke Joint | Cover 715900483

715900231

$26.49

10c

Fixed Yoke Joint

715900116

$59.49

10e

Ens. Croix*U-Joint Cross Kit

715900325

$70.99

10f

U-Joint

715900183

$26.49

10g

SNAP RING - Call your local BRP dealership

715900117

Unavailable

10h

GREASE FITTING - Call your local BRP dealership

703500813

Unavailable

25

Wear Ring | 4X4

705400036

$26.49

35

Fill Level Plug | 4X4

705500504

$10.01

36

Copper Washer | 4X4

705500506

$0.45

40

RH CV Joint | XMR

705401878

$275.49

40a

CV Joint

705401407

$259.49

40b

Boot Kit, Wheel Side

705401354

$42.49

40c

Boot Kit, Différential Side

705401355

$42.49

40d

RH Plunging CV Joint

715900395

$259.49

40e

Circlip Joint | Not shown

705401349

$6.50

40f

Oetiker Clamp, Large

715900260

$10.33

40g

Oetiker Clamp, Small

715900261

$5.29

40h

Oetiker Clamp, Large

715900262

$10.33

40i

Oetiker Clamp, Small

715900261

$5.29

45

LH Front Knuckle

705401548

$132.49

46

RH Front Knuckle

705401549

$104.99

50

LH CV Joint | XMR

705401877

$275.49

50a

CV Joint

705401407

$259.49

50b

Boot Kit, Wheel Side

705401354

$42.49

50c

Boot Kit, Différential Side

705401355

$42.49

50d

LH Plunging CV Joint

715900396

$259.49

50e

Circlip Joint | Not shown

705401349

$6.50

50f

Oetiker Clamp, Large

715900260

$10.33

50g

Oetiker Clamp, Small

715900261

$5.29

50h

Oetiker Clamp, Large

715900262

$10.33

50i

Oetiker Clamp, Small

715900261

$5.29

60

Ball Bearing

293350150

$52.99

80

Circlip

293370019

$4.68

90

Hex. Flange Screw M8 X 20, Scotch Grip

207582044

$1.69

100

Hex. Flange Screw, M10 X 130

230603046

$7.41

110

Hex. Flange Elastic Nut M10

233201436

$2.11

115

Conical Spring Washer 10 mm

234201474

$1.69

130

Wheel Hub

705501900

$132.49

140

Wheel Stud

250300060

$11.49

150

Conical Spring Washer M18

250200171

$7.65

160

Hex. Flange Castellated Nut M18

232291413

$7.98

170

Cotter Pin

250400036

$2.11

180

Polyurethane Hose 10000Mm Long

219704410

$56.99

185

Tie-Rap 180 mm

414115200

$0.11

200

Wheel Cap

705401318

$22.49

210

RH Wheel Ass'y

705401183

Unavailable

210

LH Wheel Ass'y

705401184

Unavailable

210a

TIRE_30X9R14 - Call your local BRP dealership | XMR

705401501

Unavailable

210b

Matte Black Rim

705401552

$148.99

210c

Not Available As Spare Parts

XXX

Unavailable

210d

Not Available As Spare Parts

XXX

Unavailable

210e

Not Available As Spare Parts

XXX

Unavailable

210f

Not Available As Spare Parts

XXX

Unavailable

210g

Not Available As Spare Parts

XXX

Unavailable

211

Rim Valve With Cap

705400193

$8.69

225

Valve Cap

293000110

$1.59

230

Black, Wheel Nut M10 X 1.25

250100184

$4.51

270

O-Ring

293250246

$7.51

290

Wear Sleeve

705400780

$7.90

310

Flat Washer M12

250200102

$2.11

320

HEX FLANGED SCREW M12 X 16, SCOTCH GRIP - Call your local BRP dealership

250000378

Unavailable
