ENGINE MOUNTING 440 XCR SP X951660 (4932833283C003)
Polaris 440 XCR SP - X951660 ENGINE MOUNTING 440 XCR SP X951660 (4932833283C003) Diagram
#
1
BOLT(10)
7512565
$19.99
2
WASHER-7/16-INT LK-(1222)-Z
7575202
$4.79
3
WASHER,CLUTCH RETAINER
5010278
Unavailable
4
O RING,(10)
5410507
$1.49
5
SPACER,CLUTCH BOLT
5020513
$44.99
6
SPARKPLUG(8)
3070165
$3.99
7
ENG.(S.B.)EC45PL05 [No Longer Available]
3085096
Unavailable
8
HANDLE-RECOIL
5430520
Unavailable
9
SCREW(10)
7512530
$5.59
10
WASHER(10)
7555740
$1.59
10
WASHER(10)
7555740
$1.59
11
MOUNT, ENGINE
5410390
Unavailable
11
MOUNT, ENGINE
5410390
Unavailable
12
TUBE,SPACER
5333354
Unavailable
13
NUT,FLANGE(10)
7542522
$5.59
14
PLATE,MTR.MT.
5240932
Unavailable
15
WASHER LOCK(10)
7553101
$3.99
16
BOLT(10)
7512539
$3.99
17
MOUNT
3110022
Unavailable
17
MOUNT
3110022
Unavailable
18
NUT LOCK(10)
7542411
$3.19
19
WASHER(10) Substituted by 7555806
7555720
$0.79
20
NUT-LOCK(10)
7542439
$1.49
21
HOSE CLAMP, RED
7080003
$1.49
21
HOSE CLAMP, RED
7080003
$1.49
21
HOSE CLAMP, RED
7080003
$1.49
21
HOSE CLAMP, RED
7080003
$1.49
22
FUEL LINE,1/4 ID(600 CM.)
8450040-600
Unavailable
22
FUEL LINE,1/4 ID(600 CM.)
8450040-600
Unavailable
23
CABLE,THROTTLE,W/OIL
7080552
Unavailable
24
NUT-LOCK(10)
7542122
$1.49
25
FUEL LINE,1/4 ID(1525 CM.)
8450003-1525
Unavailable
26
VALVE,FUEL SHUT-OFF
7052039
Unavailable
27
CABLE-TIE,DIA12-50MM,WTHR-RES.
7080138
$2.41
28
CLAMP-HOSE,(10) (Yellow)
7080236
$1.59
28
CLAMP-HOSE,(10) (Yellow)
7080236
$1.59
28
CLAMP-HOSE,(10) (Yellow)
7080236
$1.59
29
FILTER FUEL,(10)
2530008
$4.84
30
Fuel Pump (See Pg. C14, Ref. 1)
-------
Unavailable
31
FUEL LINE,1/8 ID,600 CM.
8360009-600
Unavailable
31
FUEL LINE,1/8 ID,600 CM.
8360009-600
Unavailable
31
FUEL LINE,1/8 ID,600 CM.
8360009-600
Unavailable
31
FUEL LINE,1/8 ID,600 CM.
8360009-600
Unavailable
31
FUEL LINE,1/8 ID,600 CM.
8360009-600
Unavailable
32
VENT,CHECKVALVE
7051011
Unavailable
32
VENT,CHECKVALVE
7051011
Unavailable
33
FITTING, TEE,(10)
7052048
$3.99
33
FITTING, TEE,(10)
7052048
$3.99
