Can-Am 005 - Defender MAX HD10 - North America, 2019 09- Cab Interior - XT CAB - Dash Section Diagram

Description

Price

Cup Holder

707900288

$16.99

100

Dashboard Upper Kit

715006520

$204.99

105

Torx Screw K50 X 16

250000720

$1.69

115

Torx Truss Screw M6 X 16

250000721

$1.69

1000

Drawer

707900252

$20.99

1005

O-Ring

293300194

$1.25

2200

LH Lower Dash | Except Base Package

707900251

Unavailable

2210

Torx Screw M6 X 20

250000722

$1.68

2215

Stainless Steel Flat Washer

234062670

$2.11

2220

Insert Half Hex Body M6 x 1.0

250100199

$3.19

2230

Torx Screw K50 X 16

250000720

$1.69

2250

Switch Support

703501098

$16.86

2350

Cluster Support | Package XT, Cab

707900358

$20.99

2370

Storage Box Ass'y | Includes 2370 to 2370b

703501087

$43.99

2370a

Storage Box Ass'y | Includes 2370 to 2370b

703501087

$43.99

2370b

Storage Box Ass'y | Includes 2370 to 2370b

703501087

$43.99

2380

Hex. Flange Screw K50 X 2.24 X 16

241151640

$1.47

2390

Grommet

705003264

$4.09

2400

Passenger Handhold

707900248

$49.99

2410

Torx Screw M6 X 60

250000648

$7.51

2420

M6 Nut Housing Ass'y | Includes 7r to 7r2

269500725

$4.55

2420a

M6 Nut Housing Ass'y | Includes 290 to 290b

269500252

$7.86

2420b

Hex. Elastic Stop Nut M6

232561600

$1.15

2500

Removable Storage Bin

715004344

$88.99

2510

Removable Storage Bin

715004344

$88.99

2520

Clip | Outlander Max

269501945

$15.89

2530

Handle | DPS Package

707900567

$19.99

2550

Rubber Bumper

293830005

$8.09

2560

Cap

293000120

$2.89

3000

Shifter Gate

707900608

$8.99

3010

Torx Screw M6 X 25 | XT Models

250000728

$4.44

3050

Shifter Gate Deflector

707900506

$5.69

3060

Push Nut

250100178

$0.63

4200

Central Adaptor

707900452

$16.99

4205

Front Grid

707900434

$13.99

4210

Torx-Truss Pt K40 X 16

250000759

$2.11

4215

LH Adaptor

707900437

$23.99

4220

LH Grid

707900435

$23.99

4225

RH Adaptor

707900455

$23.99

4230

RH Grid

707900436

$23.99

4235

Side Flange

707900438

$13.24

4240

Tuflok Plastic Rivet

293150230

$1.47

4245

Storage Box LWR F

707900852

$88.99

4250

Torx Screw K50 X 16

250000720

$1.69

4255

Tuflok Plastic Rivet

293150230

$1.47
